Fractures of the radius and ulna
Mechanism of injury :
Fractures of the shaft of both bones occur commonly in road traffic accidents, it can be caused by:
1- Twisting force, which cause spiral fracture in both bones in different levels.
2- Direct blow , lead to transverse fractures at the same level.
Additional rotation which lead to more displacement can be caused by
The pronator muscles (pronator teres , pronator quadratus ) in the middle and the lower
thirds .
And the supinator muscles (biceps , supinator ) in the upper third of the forearm
Clinically
:
Fracture is usually quite obvious but we should do checking of the nerves and arteries (distal
pulsation) distal to the site of the fracture which can be affected by compartment syndrome .
02
/
11
/
0212
Surgery (orthopedic) د.يقظان السليم
2 |
P a g e
Treatment
In children with green stick fracture ,
1. The closed treatment is usually successful because the thick periosteum tend to guide and
control the reduction ;
2. After reduction we put back slab above elbow which is 90` flexed and ask the patient to
elevate the limb to decrease the edema ;
3. After 10 days we change the slab to complete p.o.p.
4. if the fracture is in the upper third we put the fore arm in supination ,
5. if it in the middle third we put the fore arm in neutral and
6. if it in the distal third we put the fore arm in pronation .
7. The p.o.p. should be left for another 4 weeks .
Followed by physiotherapy .
Open reduction is indicated in :
1-if the fracture can not be reduced .
2- if the reduction is unstable .
The fixation will be by plate and screw, intramedullary nail,
In adult:
Closed reduction of this fracture in adult is very difficult and redisplacement in the cast is
common so most of the surgeons prefer the open reduction and fixation from the beginning by
plate and screws .
Open fracture: need external fixation because internal fixation cannot be used in compound
fracture
3 |
P a g e
Complication
Early:
1- Nerve injury . It is rarely occur in this fracture but it can be caused by the surgeons
e.g. posterior interosseous nerve .
2-vascular injury . Ulnar and radial arteries .
3- compartment syndrome .
Late:
1- delayed union and nonunion .
2-malunion which lead to limitation of pronation and supination .
Fracture single fore arm bone
It is much less common than the fracture of both bones .
It's importance are :
1- When one bone fractured along it's shaft ,
It is usually associated with dislocation of the proximal or the distal radio - ulnar joint, so when
there is one bone fracture x-ray should be taken to the whole length of thefore arm to detect any
dislocation .
2- non-union is liable to occur due to intact fellow bone .
4 |
P a g e
Monteggia fracture dislocation of the ulna
It is fracture of the proximal third of the ulna with dislocation or subluxation of the proximal radio-
ulnar joint .
Clinically : the ulnar deformity is usuallyobvious but the dislocated head of radius is masked by
the swelling .
X-ray : in isolated fracture ulna it is essential to take true a-p and lateral views of the elbow ; the
normal radial head is usually pointing towards the capitulum in monteggia it is not ; in addition to
appearance of the fracture
.
Montegia fracture dislocation
Montegia fracture
dislocation
5 |
P a g e
Treatment:
The most important point in treatment is to restore the length of the fractured ulna
and only in this case the dislocation will be reduced and remain stable ; so
in adult this mean operation (reduction and fixation by plate and screws) if the dislocation not
reduced , then open reduction of the joint .
In children if the fracture is green- stick then manipulation under anesthesia can be helpful, but if
the fracture is complete then open reduction and fixation like adult .
Complication:
1
- Nerve injury : which occur either due to manipulation or during surgery .
2- malunion : unless the fracture has been perfectly reduced , the radial head remain dislocated
and limiting elbow flexion , limitation of pronatiopn and supination ; if this happened in children
no treatment but if occur in adult then excision of the head of the radius can be done .
3- non union of the ulna : the treatment by rigid internal fixation and bone graft .
Galeazzi fracture dislocation of the radius
It is caused by fall on the hand , there is fracture in the lower third of the radius and dislocation of
the inferior radio- ulnar joint .
Clinically :
it is much more common than monteggia ,
prominence and tenderness over the lower end of the ulna is an important point in examination .
6 |
P a g e
Galeazzi fracture dislocation
Treatment :
the most important point is to restore the length of the fractured radius ,
other wise the dislocation will not reduced .
In children close reduction is possible but if fail , then open reduction and fixation .
In adult , the treatment will be by open reduction and internal fixation .
Complication :
The most important complication is limitation of pronation and supination .
A.L.Y
